Dimensions [mm]

Weight
(g)

Pull Force
(N)

D

d2

d1

h

H

CMNdp01-01

16

6.6

3.5

1.5

4.5

6

75

CMNdp01-02

20

9

4.5

2

6

15

105

CMNdp01-03

25

9

4.5

3

7

25

160

CMNdp01-04

32

11

5.5

3

7

40

310

CMNdp01-05

40

10.6

5.5

4

8

75

500

Part No.

Dimensions [mm]

Weight
(g)

Pull Force
(N)

D

d2

d1

h

H

CMNdp02-01

20

8

3.1

3

4.5

10

95

CMNdp02-02

25

11

6

5.5

7

20

135

CMNdp02-03

32

11.5

6

5

8

35

280

CMNdp02-04

36

12

5

5

7

47

350

CMNdp02-05

40

10

5.5

5

8

73

460

Part No.

Dimensions [mm]

Weight
(g)

Pull Force
(N)

D

h

M

H

CMNdp03-01

10

4.5

4

12.5

3

25

CMNdp03-02

13

4.5

5

12.5

5

60

CMNdp03-03

16

4.5

6

12.5

7.5

95

CMNdp03-04

20

7

5

14

16

140

CMNdp03-05

25

7

6

17

25

200

CMNdp03-06

32

7

6

17

48

350

Dimensions [mm]

Weight
(g)

Pull Force
(N)

D

h

M

H

d

CMNdp04-01

10

4.5

3

11.5

6

3

25

CMNdp04-02

13

4.5

3

11.5

6

6

60

CMNdp04-03

16

4.5

4

11.5

8

9.5

95

CMNdp04-04

20

6

4

13

8

18

140

CMNdp04-05

25

7

4

14

8

25

200

CMNdp04-06

32

7

5

15.5

10

48

350

CMNdp04-07

40

8.5

6

15.5

10

80

500

Dimensions [mm]

Weight
(g)

Pull Force
(N)

D

H

M

W

CMNdp05-01

6

6

3

2.7

0.7

5

CMNdp05-02

8

6

3

3

2

13

CMNdp05-03

12

8

4

5

3.5

60

CMNdp05-04

19

8

4

5

12

130

CMNdp05-05

20

13

5

9.5

13

140

CMNdp05-06

29

10

5

5

35

320

CMNdp05-07

50

15

8

11.5

80

550

CMNdp05-08

50

20

8

11.5

140

700

Dimensions [mm]

Weight
(g)

Pull Force
(N)

D

H

M

CMNdp06-01

6

20

2.5

10

CMNdp06-02

8

20

3.5

25

CMNdp06-03

10

20

4

4.5

45

CMNdp06-04

13

20

4

7.5

70

CMNdp06-05

15

20

4

15

110

CMNdp06-06

20

25

4

28

180

CMNdp06-07

25

35

5

45

200

CMNdp06-08

32

40

6

75

450
